Product & Assembly Information: Code 542 – 4G/Y29/S

code 542 Fibreboard box
Bottom fibreboard pad
Fibreboard bottle stabilizer box
Top fibreboard closure stabilizer pad
Top fibreboard pad

In the case of 4G packaging, the number stated on the UN specifications mark is the number corresponding to the maximum gross mass in kilograms, at which the design type has been tested. Meaning, 29kg is the gross mass weight for this specific box.

No. Each 4G packaging design has been tested and approved with the use of specific inner packaging. You must use the same inner packaging as used in the testing process. The approved inners for this 4G box are listed above.

For approved inners torque values please refer to the Torque Values information at the top of this page.

You must use the same cushioning as used in the testing process. For this specific 4G/Y29/S box, top and bottom buffer pads, plus stabilizer dividers are required to prevent movement of the inner packaging, this is the approved cushioning. Vermiculite must NOT to be used in this 4G box, it has been tested and approved without the use of vermiculite.

No. Tape come in various sizes and types, they are designed to seal 4G boxes to avoid them opening or the inner packaging escaping during transport and have been tested for their capability. You must use the same tape and method as used in the testing process. The approved tapes and taping method for this 4G box is; seal with two strips of 50mm adhesive tape in a “U” shape. This can also be found on the assembly instructions.
